MG-375 Electric Direct Drive
Provides a reliable, economical solution for a variety of PCP applications, including heavy to light oil, coalbed methane, and water source wells
Applications
• PCP applications driven by electric or hydraulic motors
Features and Benefits
• The small footprint is especially useful for height-restricted work areas and aesthetically sensitive environments.
• Standard features include a hinged guard for easy sheave and belt inspection or replacement and a two-point lifting system for ease of handling.
• The centrifugal braking system provides a resistive torque that is proportional to speed, for a safe release of the backspin energy. The brake shoes automatically engage and retract based on speed, which results in a quick, complete, and controlled fluid dump, enabling production to resume quickly.
• The braking system is enclosed and immersed in synthetic oil to manage the wide range of operating temperatures and to lubricate all moving parts for a long service life.
Tool Description
The Weatherford MG-375 is an electric, belt-driven drive with a torque capacity of 375 lbf-ft. It is compatible with Weatherford stuffing boxes and various wellhead connections.
